The book is full of photos and patent drawings; here is a typical page.
The chapters are
– The Invention and Early Development of the Multiplier Reel
– Introduction to Patents
– Frame Construction and External Features
– Freespool Clutches
– Level-Wind Mechanisms
– Machining and Engineering Features
– Quick-Takedown Features
– Et Alia
While not really directed to fly reels, it is a very interesting read. In 1985, patent images were not available on-line, so author Vernon did a tremendous amount of work to compile this book.
This is my one multiplier reel, given to me by my grandfather about 1958. Also had a one piece steel casting rod which still held its tip-top and one other line guide. This reel is stamped “Shakespeare 1905 DEUCE Model FK”.
You will occasionally see a fly reel made as a multiplier.
